LED POWER SUPPLIES

Allanson has the LED Power Supply for every lighting job! Available in multiple voltages, and wattage’s, Allanson power supplies support our entire line of LED lighting solutions. Consistency and reliability are paramount, and so we back our certified power supplies with a full 5 year warranty.

DOWNLOAD THE FULL PRODUCT BROCHURE

CV122-120-277V LED Power Supply (12V DC 24W)

  • Output Volts: 12V DC
  • Output Watts: 24W
  • Output Current: 2A
  • Input Voltage: 120-277V AC
  • Input Current: 0.27A @ 120V | 0.13A @ 277V
  • Operating Temperature: -40oC to +40oC
  • UL Class 2 rated
  • CSA certified components
  • Fully encapsulated
  • High power factor
  • Short circuit and overload protection
  • IP65 Rated for dry and damp environments
  • Dimensions 4.8”x1.58”x0.96”
  • 5 Year Warranty

DOWNLOADS

CV122-120-277V Manual

CV125-120 LED Power Supply (12V DC 60W)

  • Output Volts: 12V DC
  • Output Watts: 60W
  • Output Current: 5A
  • Input Voltage: 120V AC
  • Input Current: 0.61A
  • Operating Temperature: -40oC to +40oC
  • UL Class 2 rated
  • CSA certified components
  • Fully encapsulated
  • High power factor
  • Short circuit and overload protection
  • IP65 Rated for dry and damp environments
  • Dimensions 9.5”x1.85”x1.15”
  • 5 Year Warranty

DOWNLOADS

CV125-120 Manual

CV125-347 LED Power Supply (12V DC 60W)

  • Output Volts: 12V DC
  • Output Watts: 60W
  • Output Current: 5A
  • Input Voltage: 347V AC
  • Input Current: 0.25A
  • Operating Temperature: -40oC to +40oC
  • UL Class 2 rated
  • CSA certified components
  • Fully encapsulated
  • High power factor
  • Short circuit and overload protection
  • IP65 Rated for dry and damp environments
  • Dimensions 9.5”x1.85”x1.15”
  • 5 Year Warranty

DOWNLOADS

CV125-347 Manual

CV244-120-277 LED Power Supply (24V DC 96W)

LED POWER SUPPLY 24 VDC 96 WATT
  • Output Volts: 24V DC
  • Output Watts: 96W
  • Output Current: 4A
  • Input Voltage: 120-277V AC
  • Input Current: 0.94A @ 120V | 0.41A @ 277V
  • Operating Temperature: -40oC to +40oC
  • UL Class 2 rated
  • Fully encapsulated
  • High power factor
  • Short circuit and overload protection
  • IP65 Rated for dry and damp environments
  • Dimensions 9.5”x1.85”x1.15”
  • 5 Year Warranty

DOWNLOADS

CV244-120-277 Manual

CVW125-MV LED Power Supply (12V DC 60W) – Wet Location

LED POWER SUPPLY 12 VDC 60 WATT (Wet Location)
  • Output Volts: 12V DC
  • Output Watts: 60W
  • Output Current: 5A
  • Input Voltage: 120-277V AC
  • Input Current: 0.65A @ 120V | 0.29A @ 277V
  • Operating temperature: -40oC to +40oC
  • UL Class 2 rated
  • CSA certified components
  • Fully encapsulated
  • High power factor
  • Short circuit and overload protection
  • IP68 Rated for dry and wet environments
  • Dimensions 10.50”x2.0”x1.50”
  • 5 Year Warranty

DOWNLOADS

CVW125-MV Manual

CVW243-MV LED Power Supply (24V DC 72W) – Wet Location

LED POWER SUPPLY 24 VDC 72 WATT (Wet Location)
  • Output Volts: 24V DC
  • Output Watts: 72W
  • Output Current: 3.3A
  • Input Voltage: 120-277V AC
  • Input Current: 0.36A @ 277V
  • Operating temperature -40oC to +40oC
  • UL Class 2 rated
  • CSA certified components
  • Fully encapsulated
  • High power factor
  • Short circuit and overload protection
  • IP68 Rated for dry and wet environments
  • Dimensions 10.50”x2.0”x1.5”
  • 5 Year Warranty

DOWNLOADS

CVW243-MV Manual

ACVN-125-120-277 LED Power Supply (12V DC 60W)

  • Output Volts: 12V DC
  • Output Watts: 60W
  • Output Current: 5.0A
  • Input Voltage: 120-277V AC
  • Input Current: 1.20A @ 120V
  • Input Current: 0.70A @ 277V
  • Operating temperature -40oC to +55oC
  • UL Class 2 rated
  • CSA certified components
  • Fully encapsulated
  • Normal power factor
  • Short circuit and overload protection
  • Dimensions 5.51”x1.69”x1.18”
  • 5 Year Warranty

DOWNLOADS

ACVN125-120-277 Manual

ACV-125-120-277 LED Power Supply (12V DC 60W)

  • Output Volts: 12V DC
  • Output Watts: 60W
  • Output Current: 5.0A
  • Input Voltage: 120-277V AC
  • Input Current: 0.59A @ 120V
  • Input Current: 0.26A @ 277V
  • Operating temperature -40oC to +55oC
  • UL Class 2 rated
  • CSA certified components
  • Fully encapsulated
  • High power factor
  • Short circuit and overload protection
  • Dimensions 6.50”x1.68”x1.18”
  • 5 Year Warranty

DOWNLOADS

ACV125-120-277 Manual

ACV-2125-120-277 LED Power Supply (12V DC 2x60W)

  • Output Volts: 12V DC
  • Output Watts: 120W (2 x 60W)
  • Output Current: 5.0A + 5.0A
  • Input Voltage: 120-277V AC
  • Input Current: 1.15A @ 120V
  • Input Current: 0.50A @ 277V
  • Operating temperature -40oC to +55oC
  • UL Class 2 rated
  • CSA certified components
  • Fully encapsulated
  • High power factor
  • Short circuit and overload protection
  • Dimensions 11.75”x1.69”x1.18”
  • 5 Year Warranty

DOWNLOADS

ACV2125-120-277 Manual

ACV-3125-120-277 LED Power Supply (12V DC 3x60W)

  • Output Volts: 12V DC
  • Output Watts: 180W (3 x 60W)
  • Output Current: 5.0A + 5.0A + 5.0A
  • Input Voltage: 120-277V AC
  • Input Current: 1.70A @ 120V
  • Input Current: 0.75A @ 277V
  • Operating temperature -40oC to +55oC
  • UL Class 2 rated
  • CSA certified components
  • Fully encapsulated
  • High power factor
  • Short circuit and overload protection
  • Dimensions 16.70”x1.69”x1.18”
  • 5 Year Warranty

DOWNLOADS

ACV3125-120-277 Manual

CVW-125-120-277 LED Power Supply (12V DC 60W) – Wet Location

  • Output Volts: 12V DC
  • Output Watts: 60W
  • Output Current: 5.0A
  • Input Voltage: 120-277V AC
  • Input Current: 0.70A @ 120V
  • Input Current: 0.30A @ 277V
  • Operating temperature -40oC to +40oC
  • UL Class 2 rated
  • CSA certified components
  • Fully encapsulated
  • High power factor
  • Short circuit and overload protection
  • IP68 Rated for dry and wet environments
  • Dimensions 9.54”x1.54”x1.16”
  • 5 Year Warranty

DOWNLOADS

CVW125-120-277 Manual

CVW-2125-120-277 LED Power Supply (12V DC 2x60W) – Wet Location

  • Output Volts: 12V DC
  • Output Watts: 120W (2 x 60W)
  • Output Current: 5.0A + 5.0A
  • Input Voltage: 120-277V AC
  • Input Current: 1.40A @ 120V
  • Input Current: 0.60A @ 277V
  • Operating temperature -40oC to +40oC
  • UL Class 2 rated
  • CSA certified components
  • Fully encapsulated
  • High power factor
  • Short circuit and overload protection
  • IP68 Rated for dry and wet environments
  • Dimensions 9.22”x2.68”x1.34”
  • 5 Year Warranty

DOWNLOADS

CVW2125-120-277 Manual

CVW-3125-120-277 LED Power Supply (12V DC 3x60W) – Wet Location

  • Output Volts: 12V DC
  • Output Watts: 180W (3 x 60W)
  • Output Current: 5.0A + 5.0A + 5.0A
  • Input Voltage: 120-277V AC
  • Input Current: 1.80A @ 120V
  • Input Current: 0.80A @ 277V
  • Operating temperature -40oC to +40oC
  • UL Class 2 rated
  • CSA certified components
  • Fully encapsulated
  • High power factor
  • Short circuit and overload protection
  • IP68 Rated for dry and wet environments
  • Dimensions 11.7”x2.68”x1.52”
  • 5 Year Warranty

DOWNLOADS

CVW3125-120-277 Manual

CVW-244-120-277 LED Power Supply (24V DC 96W) – Wet Location

  • Output Volts: 24V DC
  • Output Watts: 96W
  • Output Current: 4.0A
  • Input Voltage: 120-277V AC
  • Input Current: 0.95A @ 120V
  • Input Current: 0.40A @ 277V
  • Operating temperature -40oC to +40oC
  • UL Class 2 rated
  • CSA certified components
  • Fully encapsulated
  • High power factor
  • Short circuit and overload protection
  • IP68 Rated for dry and wet environments
  • Dimensions 9.59”x1.81”x1.25”
  • 5 Year Warranty

DOWNLOADS

CVW244-120-277 Manual

CVW-2244-120-277 LED Power Supply (24V DC 2x96W) – Wet Location

  • Output Volts: 24V DC
  • Output Watts: 192W (2 x 96W)
  • Output Current: 4.0A + 4.0A
  • Input Voltage: 120-277V AC
  • Input Current: 2.23A @ 120V
  • Input Current: 0.99A @ 277V
  • Operating temperature -40oC to +40oC
  • UL Class 2 rated
  • CSA certified components
  • Fully encapsulated
  • High power factor
  • Short circuit and overload protection
  • IP68 Rated for dry and wet environments
  • Dimensions 9.22”x2.68”x1.52”
  • 5 Year Warranty

DOWNLOADS

CVW2244-120-277 Manual

CVW-3244-120-277 LED Power Supply (24V DC 3x96W) – Wet Location

  • Output Volts: 24V DC
  • Output Watts: 288W (3 x 96W)
  • Output Current: 4.0A + 4.0A + 4.0A
  • Input Voltage: 120-277V AC
  • Input Current: 3.35A @ 120V
  • Input Current: 1.51A @ 277V
  • Operating temperature -40oC to +40oC
  • UL Class 2 rated
  • CSA certified components
  • Fully encapsulated
  • High power factor
  • Short circuit and overload protection
  • IP68 Rated for dry and wet environments
  • Dimensions 12.96”x2.68”x1.52”
  • 5 Year Warranty

DOWNLOADS

CVW3244-120-277 Manual
